Includes Freight and Prep
Delivery within 100 Miles
INCLUDED IN THE PRICE:
*Cash Price
**Based on Finance Price
Sales tax not included
At Ravenscraft Implement, we stock a wide selection of Land Pride implements ready to pair with your new Kubota tractor-from box blades and rotary cutters to quick hitches and grading tools. These are just a few of the options available, and we can easily custom-build a package to match your property needs while still qualifying for Kubota’s special financing and package programs. Our goal is to help you find the perfect tools to work your ground — efficiently, affordably, and locally.
“Ravenscraft Implement made buying my tractor simple. Straight answers and fast delivery.”
“Great people. They went through every detail of the Grand L and made the process easy.”
“Delivered to my property right on time. Excellent experience from start to finish.”
Factory Climate-Controlled Cab — Heat, A/C, defrost, and insulation for year-round comfort.
K Command Display — Access customizable tractor settings, hands-free calling, and Bluetooth® wireless technology through a vibrant color display that puts advanced control and information at your fingertips.
LA806 Loader Compatibility — Strong lift, smooth geometry, and under-boom line routing.
LED Headlights + DRLs — Excellent visibility day or night.
Optional Air-Ride & Heated Air-Ride Seating — Comfort upgrade for long days.
Rugged Grand-L Chassis — Heavy, stable platform for loader work & snow removal.
The L3770DLXC is the Deluxe cab model, while the PRMC versions add joystick upgrades, premium electronics, and the Cold Weather Package.
The L3770DLXC gives you the comfort, loader strength, and reliability of the Grand L. PRMC adds electronics, joystick functions, and the Cold Weather Package.
| Engine — Gross HP | 37.0 hp |
| PTO HP | 28.0 hp (540 rpm) |
| Transmission | iHST+ Hydrostatic — 3-range |
| Hydraulic Flow | 8.0 gpm |
| 3-Point Hitch | Category I |
| 3-Pt Lift Capacity | 3,750 lbs @ ball ends 2,650 lbs @ 24" |
| Loader Compatibility | LA806 Loader |
| Overall Width | 59.8 in |
| Wheelbase | 71.1 in |
| Overall Length | 115.9 in |
| Ground Clearance | 14.2 in |
| Fuel Capacity | 13.5 gal |
| Operating Weight (Cab) | 4,034 lbs |
| Cab Features |
• Factory ROPS Cab • Heat & A/C • Defrost Vents • Rear Wiper • Improved Insulation |
| Seat Options |
• Mechanical Grammer Seat • Optional Air-Ride • Optional Heated Air-Ride |
| Optional Features |
• 3rd-Function Hydraulics • Under-Boom LEDs • Brush Guard • Camera Kits (Premium Models) |
| Loader Model | LA806 |
| Lift Height | 105.4 in |
| Lift Capacity | 1,726 lbs |
| Lift @ 500mm | 1,350–1,420 lbs |
| Breakout Force | ~3,634 lbs |
| Reach at Ground | 74.2 in |
| Dump Angle | 55° |
| Rollback Angle | 40.6° |
| Cycle Times |
Raise: 3.9–4.2 sec Lower: 3.0–3.4 sec Dump: 2.2–2.5 sec Rollback: 2.1–2.4 sec |
| Bucket Width | 72" HD |
| Bucket Capacity | 0.44 cu yd |
| Quick Attach | 2-Lever Skid Steer |
| Hydraulic Routing | Under-boom (clean visibility) |
| Options |
• 3rd-Function Valve • Under-Boom LEDs • Brush Guard • Dual-Function Valve • MSL NOT available (5070/6070 only) |
| Loader Weight | 780–820 lbs |
Delivery available within 100 miles of Whitewater, KS.
