Kubota LX2620HSD Package Deal

Kubota LX2620HSD Package Price $28,430*

Payments As Low as $403.39**

Includes Freight and Prep
Delivery within 100 Miles

*Cash Price
**Based on Finance Price
Sales tax not included

The Kubota LX2620HSD tractor package pairs a 24.8 HP compact utility tractor with LA535 loader, Land Pride QH16 quick hitch, BB1260 box blade and RCR1260 rotary cutter. It’s a turn-key setup for 3–20 acre properties around Wichita, Newton, El Dorado and Whitewater, Kansas.

Kubota LX2620HSD tractor package with LA535 loader and Land Pride implements in Kansas
Kubota LX2620HSD tractor and LA535 loader with Land Pride implements

What’s Included in This Kubota LX2620HSD Tractor Package

Kubota LX2620HSD Tractor – Compact Utility Platform +
Kubota LX2620HSD tractor and loader
Kubota LX2620HSD compact utility tractor with loader

This package starts with a Kubota LX2620HSD compact utility tractor:

  • Deluxe compact chassis – more tractor than a sub-compact, still easy to maneuver.
  • 4WD with power steering for confident loader work and mowing on slopes.
  • Open station operator platform with ergonomic controls and flat deck.
  • Category 1 three-point hitch – ready for box blades, cutters, and other implements.
  • Rear PTO for rotary cutters and other PTO-driven tools.

It’s a great “do-everything” tractor for acreage, mowing, loader work, and light farm chores.

3-Range Hydrostatic (HST) Transmission +
Kubota LX2620HSD operator station and hydrostatic controls
LX2620HSD operator station with hydrostatic treadle pedal

The HSD in LX2620HSD means hydrostatic drive – ideal for loader work and mowing:

  • 3-range HST (Low, Medium, High) for precise control from slow work to transport speed.
  • Treadle-style pedal – rock your foot forward or back to change direction.
  • Excellent for loader work, mowing around obstacles, and tight spaces.
  • Smooth, car-like operation – easier for new operators and family members to drive.

If you’re doing a mix of loader work and finish mowing, HST is the right transmission for this tractor.

R4 Industrial Tires Front & Rear +
Kubota LX2620HSD tractor package with R4 industrial tires
LX2620HSD equipped with R4 industrial tires

This package is equipped with R4 industrial tires – a great middle ground for mixed use:

  • Flatter, more stable footprint than Ag tires for loader work and mowing.
  • More traction than turf tires on dirt, gravel, and light field work.
  • Good choice for driveways, building sites, and pasture edges.
  • Durable sidewalls for loader and pallet fork work.

R4s are a strong choice when you need one tire that can handle loader work, light field work, and yard jobs.

Kubota LA535 Loader with Skid Steer QA Bucket +
Kubota LA535 front loader with skid steer quick attach bucket
Kubota LA535 loader with skid steer–style quick attach bucket

This package includes the Kubota LA535 front loader, factory-matched for the LX Series chassis:

  • Skid steer quick attach (SSQA) – swap between bucket and pallet forks in seconds.
  • Greater lift capacity than the LA435, ideal for gravel, dirt, and pallet handling.
  • Full-function joystick control for smooth raise, lower, curl, and dump.
  • Designed specifically for the LX2620 platform for balance and stability.

The LA535 gives this package true compact utility tractor performance — not sub-compact capability.

Land Pride QH16 Category 1 Quick Hitch +
Land Pride QH16 quick hitch
Land Pride QH16 Category 1 quick hitch

We include a Land Pride QH16 quick hitch to make changing 3-point implements easier:

  • Category 1 quick hitch sized perfectly for the LX2620HSD.
  • Hook up compatible implements without getting off the tractor as often.
  • Reduces wrestling with pins and lower arms for box blades, cutters, and more.
  • Heavy-duty frame built to match Land Pride implements.

Once you run a quick hitch, switching between your BB1260 and RCR1260 becomes much faster and easier.

Land Pride BB1260 Box Blade (60") +
Land Pride BB1260 60 inch box blade
Land Pride BB1260 60" box blade

The package includes a Land Pride BB1260 60" box blade:

  • Perfect width match for the LX2620 chassis.
  • Adjustable scarifiers for cutting into hard packed gravel or dirt.
  • Great for driveway maintenance, crown work, and light drainage shaping.
  • Heavy rear blade for smoothing and finishing passes.

This is your go-to tool for keeping gravel driveways, lanes, and building pads in shape.

Land Pride RCR1260 Rotary Cutter (60") +
Land Pride RCR1260 rotary cutter
Land Pride RCR1260 60" rotary cutter

Rounding out the package is a Land Pride RCR1260 60" rotary cutter:

  • 60" cutting width – ideal match for the LX2620’s size and PTO power.
  • Designed for pasture clipping, field edges, and light brush.
  • Shear bolt or slip clutch driveline (per spec) to help protect the gearbox.
  • Tailwheel for consistent cutting height and a smoother finish.

This cutter lets you keep pastures, road ditches and rough areas under control with the same tractor.

Why Buy This Kubota LX2620HSD Tractor Package

This LX2620HSD package is built for property owners who need more tractor than a BX but still want something easy to drive, easy to store, and easy to live with. With hydrostatic transmission, R4 tires, a quick-attach loader, and matched Land Pride implements, it’s a turn-key setup for mowing, driveway work, and pasture maintenance around Kansas acreages.

  • Right-size chassis between sub-compact and L-Series.
    The LX2620HSD gives you more weight, lift, and stability than a BX for loader and ground work, but is still compact enough to fit in most garages, lean-tos, and barn bays.
  • Hydrostatic drive makes it easy for anyone to run.
    The 3-range HST with treadle pedal is simple and forgiving for new operators: just press forward to go, back to reverse. Perfect for loader work around buildings, corrals, and trees.
  • R4 industrial tires for mixed use.
    R4s give you a solid footprint for loader and pallet fork work while still behaving well on gravel and yard areas—ideal for driveways, barn lots, and light pasture work.
  • Loader, quick hitch, box blade, and rotary cutter included.
    The LA435 loader with skid steer QA bucket, Land Pride QH16 quick hitch, BB1260 box blade, and RCR1260 rotary cutter give you a complete tool set on day one: move material, maintain your drive, and keep grass and pasture under control.
  • Matched to 3–20 acre properties.
    This package is sized right for customers with acreage around Wichita, Newton, El Dorado, and surrounding Kansas towns who need one tractor to handle mowing, loader work, and general clean-up without stepping into a full-sized utility machine.
  • Built and supported locally at Ravenscraft Implement.
    You’re buying from a dealership that’s been in business since 1962, with parts, service, and Land Pride implements in stock to keep your LX2620 working for years.
Welcome to Ravenscraft Implement Package Deals

In Business Since 1962

Below we have listed Land Pride Implements that we keep in stock which are only a fraction of the different tools available and we certainly encourage you to know that we can customize a package for you and still use Kubota's special package programs and get you the perfect tools to work your ground.

⭐⭐⭐⭐⭐ Customer Reviews — Kubota LX2620HSD

★★★★★

“Perfect size for our property.” The LX2620HSD has the power of a compact tractor but is easy to maneuver around buildings and trees.

— Mark T., Wichita, KS


★★★★★

“Hydrostatic transmission is so smooth.” Loader work is simple and responsive. Exactly what we needed for gravel and landscaping.

— Sarah L., Newton, KS


★★★★★

“Great dealership experience.” Kelly and Dan made the process easy from financing to delivery.

— Chris D., El Dorado, KS

Average Rating: ★★★★★ (5.0/5)
Based on verified Kansas customer reviews

See more reviews on Google

⭐ View Google Reviews

Kubota LX2620HSD Tractor Specifications

Engine & Power +
  • Engine horsepower: 24.8 HP
  • PTO horsepower: approx. 19.5 HP
  • Engine type: Kubota 3-cylinder liquid-cooled diesel
  • Engine displacement: approx. 100 cubic inches
  • Emissions system: No DPF / No DEF
  • Fuel system: Mechanical injection
Drivetrain & Transmission +
  • Transmission: 3-Range Hydrostatic (HST)
  • Drive: 4WD
  • Steering: Power steering
  • Differential lock: Standard rear differential lock
  • Brakes: Wet disc
PTO & 3-Point Hitch +
  • Rear PTO: Standard
  • PTO speed: 540 RPM
  • PTO engagement: Independent PTO
  • 3-point hitch: Category 1
  • Hitch control: Position control
  • Lift capacity at lift points: approx. 1,680 lbs
Hydraulics +
  • Total hydraulic flow: approx. 8.3 GPM
  • Power steering flow: approx. 4.0 GPM
  • Implement flow: approx. 4.3 GPM
  • Rear remote valves: Optional
Dimensions & Weight +
  • Overall width (R4 tires): approx. 55–57 inches
  • Wheelbase: approx. 65.6 inches
  • Ground clearance: approx. 13.6 inches
  • Operating weight (tractor only): approx. 1,700–1,900 lbs
  • Operating weight with loader: approx. 2,700–3,000 lbs

(Weights and dimensions vary slightly by tire and attachment configuration.)

Kubota LA535 Front Loader Specifications

General Loader Information +

The Kubota LA535 is the factory-matched front loader for the LX2620HSD compact tractor. It’s built by Kubota for strong lift performance and smooth operation with the hydrostatic transmission.

  • Matching tractor models: Kubota LX2620 series
  • Mount type: Quick-detach loader frame
  • Bucket interface: Skid steer–style Quick Attach (QA)
  • Standard bucket: 60"–66" front bucket (dealer configured)
  • Hydraulic control: Single joystick valve mounted at operator station

(Exact bucket width and options can vary by unit; ask us to match it to your work.)

Lift Height & Reach +
  • Maximum lift height to pivot pin: approx. 94 in
  • Clearance with bucket dumped: approx. mid–70 in range
  • Reach at maximum height (dump): approx. mid–20 in range
  • Reach at ground level: approx. mid–60 in range
  • Bucket dump angle (max): approx. 40°
  • Bucket rollback angle (ground level): approx. 30°–32°

These numbers are representative LA535 specs and are very close to Kubota’s published data. Perfect for loading gravel, mulch, and material into pickups, smaller dumps, and trailers.

Lift Capacity & Breakout Force +
  • Lift capacity at pivot pin: approx. 1,100–1,150 lbs
  • Lift capacity 500mm forward: approx. 800–900 lbs
  • Breakout force at pivot pin: strong enough for typical acreage gravel and dirt work
  • Lift performance: well matched to LX2620 chassis for stability with loaded bucket

For most customers, this translates into being able to move full buckets of gravel, soil, and rock, lift pallets of feed or materials (within rating), and handle day-to-day acreage chores confidently.

Hydraulics, Controls & Attachments +
  • Loader valve: 2-function joystick (raise/lower, curl/dump)
  • Hydraulic power source: Tractor implement pump (shared with 3-pt)
  • Attachment interface: Skid steer QA for buckets, pallet forks, and other front tools
  • Detachable design: Loader can be removed when not needed to reduce weight and length
  • Recommended front implements: QA bucket (included), pallet forks, snow pusher, light grapples

With the skid steer quick attach, it’s easy to keep the LA535 on the tractor full time and swap between bucket work, pallet forks, and seasonal attachments as needed.

Kubota LX2620HSD Tractor Package — Frequently Asked Questions

What comes in this LX2620HSD tractor package? +

This package includes the Kubota LX2620HSD 4WD tractor with 3-range hydrostatic transmission, R4 industrial tires, the LA535 front loader with skid steer quick attach bucket, plus a Land Pride QH16 quick hitch, BB1260 box blade, and RCR1260 rotary cutter. It’s a complete, ready-to-work setup for acreage owners.

Is the LX2620HSD bigger than a BX series tractor? +

Yes. The LX2620HSD is a compact utility tractor, not a sub-compact. It has more weight, more lift capacity, and more stability than a BX, but is still compact enough to fit in most garages and barn bays and maneuver around buildings and trees.

What is the benefit of the hydrostatic transmission? +

The 3-range HST lets you change direction with a foot pedal instead of shifting gears. It’s excellent for loader work, mowing around obstacles, and tight areas. It also makes the tractor easier for multiple family members to operate, since it feels more “automatic” than a gear-drive machine.

What can the LA535 loader lift? +

The LA535 loader has approximately 1,100–1,150 lbs lift capacity at the pivot pin and roughly 800–900 lbs at 500mm forward. In real-world terms, that’s well suited for gravel, dirt, mulch, manure, and light pallet work when operated within the rated capacity and with proper ballast.

Are R4 tires good for mowing and driveway work? +

R4 industrial tires are a strong all-around choice. They offer more traction and durability than turf tires for loader and box blade work, while still being manageable on lawns when operated with care. They are ideal for customers doing a mix of driveway maintenance, barnyard work, and light pasture mowing.

What size property is this package best suited for? +

The LX2620HSD package is typically ideal for 3–20 acre properties around Wichita, Newton, El Dorado, Hutchinson, and surrounding Kansas towns. It’s big enough for serious work, but still compact enough to handle mowing, loader work, and tight spaces around buildings and trees.

Does the price include freight, prep, and delivery? +

Yes. Your listed package price includes freight and dealer prep, plus delivery within 100 miles of Whitewater, KS. Sales tax is not included, and financing is available with approved credit through Kubota.

Ready to Get Your Kubota LX2620HSD Tractor Package?

Cash Price $28,430 • Payments as low as $403.39** • Delivery Within 100 Miles of Whitewater, KS
Call or email our sales team today to customize your LX2620 package or get a financing quote.

☎️ Call Ravenscraft Implement ✉️ Email Sales ? View Tractor & Loader Only Option ⚙️ Build Your Own Kubota Package ? View LX Series Brochure

Ravenscraft Implement • 223 S. Main St. • Whitewater, KS 67154 • (316) 799-2141
Serving Wichita • Newton • El Dorado • Hutchinson • and surrounding Kansas counties since 1962

**Payment examples are estimates with approved credit through Kubota; terms and rates may vary.

Popular Land Pride Options

Land Pride QH-16 Quick Hitch

Land Pride QH-16 3-Point Quick Hitch

Cash Price $675 or $8.64 per mo
Details »

Land Pride BB1260 60″ Box Blade

Cash Price $1,025 or 13.12 Per Month
Details »

Land Pride BB1266 66″ Box Blade

Cash Price $1,175 or $15.04 per mo
Details »

Land Pride GS1560 60″ Grading Scraper

Cash Price $1,875 or $24.00 per mo
Details »

Land Pride GS1572 72″ Grading Scraper

Cash Price $2,100 or $26.88 per mo
Details »

Land Pride RCR1860 60″ Rotary Cutter

Cash Price $2,850 or $36.47 per mo
Details »

Land Pride FDR1660 60″ 3-Point Finish Mower

Cash Price $3,500 or $44.79 per mo
Details »

Land Pride PFL2042 2000lb 42″ Pallet Forks

Cash Price $1,175 or $15.04 per mo
Details »
Skid Steer QA

Kubota Skid Steer QA For Loader Attachments L02

Cash Price $765 or $9.79 per mo
Details »

Land Pride 380-363A FF 3rd Function Valve L02 Flat Face

Cash Price $1,325 or $16.96 per mo
Details »

Land Pride SGC0660 60″ Claw Grapple (Requires 3rd Function Valve)

Cash Price $2,675 or $34.23 per mo
Details »

Land Pride SA10-20-53-11 9″ Auger For BX and B Series

Cash Price $2,975 or $38.07 per mo
Details »

Land Pride SPL1072 72″ Snow Pusher

Cash Price $1,575 or $20.16 per mo
Details »

Land Pride DH1572 72″ Disc

Cash Price $2,900 or $37.11 per mo
Details »

Land Pride AG1572 72″ Arena Groomer W/Pipe Roller

Cash Price $2,850 or $36.47 per mo
Details »

Land Pride RB1572 72″ 3-Point Rear Blade

Cash Price $950 or $12.16 per mo
Details »

Land Pride FSP700 Fertilizer Spreader

Cash Price $1,200 or $15.36 per mo
Details »

Land Pride PD15 Post Hole Digger with 9″ Auger

Cash Price $1,925 or $24.64 per mo
Details »

Kubota UB25 Utility Bucket

Cash Price $1,625 or $20.80 per mo
Details »

Land Pride RTR1258 58″ Reverse Tine Tiller

Cash Price $3,350 or $42.87 per mo
Details »

Land Pride FDR1672 72″ 3-Point Rear Discharge Finish Mower

Cash Price $3,800 or $48.63 per mo
Details »

Bio-Ballast Non-Corrosive L-02 Series Rear Tire Fill 650Lbs

Cash Price $550 or $6.84 per mo
Details »

Land Pride RG1060 60″ Root Grapple (3rd Function Valve Required)

Cash Price $3,500 or $44.79 per mo
Details »

Land Pride STB1072-01-30 72″ Snow Trip Blade

Cash Price $2,600 or $33.27 per mo
Details »

Land Pride LR1672 72″ 3-Point Landscape Rake

Cash Price $1,375 or $17.60 per mo
Details »

Land Pride SP2072 72″ Soil Pulverizer

Cash Price $2,800 or $35.83 per mo
Details »

Kubota BH77 7’7″ Dig Depth BackHoe L02

Cash Price $11,925 or $141.25 per mo
Details »

Kubota BH77 Thumb Kit

Cash Price $625 or $8.21 per mo
Details »
