Land Pride DH1590 90″ Disc

Cash Price $3,825 or $55.86 per mo

Land Pride DH1590 Disc Harrow – 90″ Heavy-Duty Tandem Disc

Cover more acres in less time with the Land Pride DH1590 Disc Harrow. Designed for 40 to 65 horsepower tractors, the DH1590 is the largest model in the DH15 Series, making it an outstanding choice for larger food plots, pasture renovation, wildlife habitat, landscaping projects, and small farm field preparation. With a full 90-inch working width, twenty-four 18-inch heat-treated disc blades, and an 865-pound heavy-duty frame, the DH1590 provides excellent soil penetration while creating a smooth, consistent seedbed. Adjustable front and rear gang angles allow operators to match cutting aggressiveness to soil conditions, making this a versatile implement for everything from breaking up residue to final seedbed preparation.

Fits

  • Kubota L3902
  • Kubota L4701
  • Kubota L4802
  • Kubota Grand L Series
  • Kubota MX4900
  • Kubota MX5400
  • Kubota MX6000
  • Kubota M Series
  • Utility tractors 40–65 HP
  • Category I & II 3-Point Hitch
  • Land Pride Quick Hitch Compatible

Key Features

  • 90-inch working width
  • Twenty-four 18-inch notched or smooth heat-treated disc blades
  • Heavy-duty 865-pound operating weight for superior penetration
  • Four adjustable front gang angles: 0°, 7°, 14°, and 21°
  • Three adjustable rear gang angles: 7°, 14°, and 21°
  • Heavy-duty 2½-inch square tubular frame
  • 3″ × 2″ gang tubes with 1-inch high-carbon steel gang axles
  • Self-aligning sealed ball bearings for long service life
  • Optional adjustable disc scrapers to reduce soil buildup
  • Optional 9-inch center sweep to eliminate center ridging

Ideal Applications

  • Large food plot preparation
  • Pasture renovation
  • Wildlife habitat establishment
  • Seedbed preparation
  • Incorporating fertilizer, lime, and crop residue
  • Commercial landscaping
  • Small farms and acreage management
  • Municipal and park maintenance

Important

The DH1590 is an excellent choice for operators wanting maximum coverage without moving to a pull-type or heavier DH25 Series disc. It pairs exceptionally well with Kubota MX and M Series tractors, while Grand L owners with adequate ballast can also take advantage of its wide working width. If you’re routinely breaking virgin sod, working heavy clay, or operating tractors over 65 horsepower, the DH25 Series offers additional weight and heavier construction for even more demanding tillage applications.

Owners Manual
